Wuque Studio BOOG75 Assembled Edition - Induction Coil

Produktbeskrivelse

DatatilbehørTastatur og tilbehørGaming tastatur fra Wuque Studio

Vi introduserer BOOG75, en magnetisk brytervariant populære ZOOM75, designet for presis spillkontroll.

Opplev forskjellen med magnetiske brytere som bruker en nedre Hall-sensor og en øvre magnet. Aktiveringspunktet bestemmes ved å evaluere styrken til den induserte strømmen, noe som gir unik og presis kontroll i hver spillsituasjon.

Med automatisk kalibrering via Baseline Calibration-algoritmen, sikrer BOOG75 jevn ytelse til tross for temperatur, fuktighet eller magnetiske forskjeller.

Få overtaket med justerbare aktiveringspunkter, fra 0,1 mm til 4,0 mm. Tilpass aktiveringsavstanden til hver tast for å finne din ideelle reiseavstand for nøkkelen og heve spillopplevelsen din med BOOG75.

Keyboard Specifications:

• Gasket Mount Design
• ANSI Layout
• 75% Layout
• PCB: 1.6mm, with Ai03 DB
• 5° Typing angle
• 22.14 mm front height
• Dimension: 323.6 x 145.78 x 34.73 (mm)
• Default plate: Alu
• Case Material: 6063 Aluminum
• Case Finish: Anodized+Infill (No Sparkles, No Chamfer)
• Backplate and External Weight: Anodized+Infill
• Switches Type: Gateron KS37B
• The Orientation of the Switches: North Facing
• No SS Internal Weight
• Boog75 Wired Polling Rate: 1000hz
• QMK or VIA Support: No, customization requires to use of our independent driver.
• Total weight: About 3kg

Keycap Specifications:

• Manufacturer: WS PBT
• Keycap Material: Doubleshot PBT
• Keycap Thickness: 1.6mm
• Keycap Profile: Cherry
• Keys QTY: 81 keys

Switch Specifications:

• Product Name: GATERON KS-37B Magnetic Hall Sensor Keyboard Switch
• Initial Force:30±10gf.
• Total travel:4.0±0.2mm.
• Operation Lifetime:150,000,000 Cycles.
• Bottom Force: 50±10gf.
• Top Housing Material: Thermoplastic, Transparent
• Bottom Housing Material: Thermoplastic, Red
• Stem Material: Thermoplastic, Red
• Spring Material: Stainless steel

Highlights:

• Dual-rail structure for stability.
• Square magnet design, with freely adjustable magnetic pole orientation. Supports multi-directional Hall effect sensing.
• Extended the stem for better switch stability.
• Integrated spotlight lens design, enhancing light guidance.
• Every switch features a very tight housing and a perfect coat of factory lube. No need to spend hours and hours lubing switches, they are good to go off the pack!

Kit Contents:

Fully Assembled Keyboard, including:

1. Top and bottom cases
2. HE Module(Magnetic Switch, Plate, Gasket, Sound absorbing foam, and PCB)
3. Case foam
4. The themed keycaps
5. Tool accessories

Artikkelnummer

Vårt artikkelnummer: 29768
Produsentens artikkelnr: WS-BOOG75-IND-CL
